Journeyer Sora 700c has everything you need for dipping into the world of dirt-road rides. The all-new aluminum frame and our Waxwing carbon fork deliver comfort and poise on rough roads but are just as enjoyable on the pavement and paths around town. You’ll find mounts for fenders, racks, Anything Cages, and other ride accessories, making it easy to carry whatever you need for your gravel ride, commute, or bikepacking outing. The 700c wheels and 38 mm tires roll surely and speedily over asphalt, dirt, and gravel for lacing together all-road adventures that don’t have to end where the pavement does. Shimano’s Sora 2 x 9-speed components have plenty of gear range on tap for whatever your ride goals may be. We believe Journeyer Sora 700c has all the best adventure bike features in an accessible package. Time to start making plans
Specs
Frame |
Journeyer Drop-Bar Thru-Axle |
Fork |
Waxwing |
Front Derailleur |
Shimano Sora R3000 |
Rear Derailleur |
Shimano Sora R3000, Medium Cage |
Cassette |
Shimano HG200, 11–34t, 9-speed |
Chain |
KMC X9 |
Crankset |
Shimano MT210, 46/30t |
Shifter |
Shimano Sora R3000 |
Brakes |
Tektro MD-C550 |
Rotors |
Tektro TR160-22 rotors (6-bolt, 160 mm) |
Bottom Bracket |
68 mm BSA |
Headset |
FSA NO.42 ACB IS-2 |
Stem |
Salsa Guide 31.8, 6-degree |
Handlebar |
Salsa Cowbell 3, 31.8 |
Grips/Tape |
Black Cork |
Seatpost |
Salsa Guide, 27.2 x 350 mm |
Saddle |
WTB Volt Medium, Steel, 142 x 265 mm |
Front Wheel |
WTB Serra 12 x 100 mm hub, WTB ST i23 700c rim, 28h |
Rear Wheel |
WTB Serra HG10 12 x 142 mm hub, WTB ST i23 700c rim, 28h |
Tires |
Teravail Washburn, 700c x 38 mm, 30 tpi |
Weight |
24 lb (56 cm, with pedals) |
Geometry
Size |
49 |
51 |
53 |
55 |
57 |
60 |
Top Tube Effective |
493 |
510 |
530 |
550 |
570 |
600 |
Standover |
613.5 |
648.5 |
684.5 |
720.5 |
756.5 |
803.5 |
Reach |
366 |
368 |
372 |
376 |
387 |
408 |
Crank Arm Length |
170 |
170 |
170 |
170 |
175 |
175 |
Stack |
510 |
528 |
552 |
570 |
598 |
627 |
Total Seat Tube Length |
340 |
380 |
410 |
450 |
490 |
520 |
Head Tube Length |
90 |
105 |
130 |
150 |
180 |
210 |
Head Tube Angle |
68.5 |
69.5 |
69.5 |
69.5 |
69.5 |
69.5 |
Seat Tube Angle |
76 |
75 |
74 |
73 |
73 |
73 |
Handlebar Width |
380 |
400 |
420 |
440 |
460 |
460 |
Bottom Bracket Drop |
70 |
70 |
70 |
70 |
70 |
70 |
Chainstay Length |
440 |
440 |
440 |
440 |
440 |
440 |
Fork Length Axle to Crown |
402 |
402 |
402 |
402 |
402 |
402 |
Fork Offset |
50 |
50 |
50 |
50 |
50 |
50 |
Wheelbase |
1027 |
1028 |
1040 |
1050 |
1072 |
1104 |
Recommended Rider Height |
142 - 152cm |
150 - 160cm |
157 - 170cm |
165 - 178cm |
173 - 185cm |
183 - 196cm |
Stem Length |
60 |
70 |
80 |
80 |
90 |
100 |
Wheel Size |
700C |
700C |
700C |
700C |
700C |
700C |
