Jamis Trail XR S/O
$399.00
Availability: In Stock
QUALITY, VERSATILITY, AFFORDABILITY
The Trail XR is built for the rider looking for quality, versatility and affordability in a bike that can handle city streets, rail trails, campus short cuts and suburban cul-de-sacs with comfort and confidence. Inspired by our Trail X mountain bikes, but tuned for everyday ‘round-town regular riding, the XR is the perfect fat-tired solution for the buyer on a budget.
Specs
| Frame | Hi-tensile steel tubes |
|---|---|
| Fork |
Unicrown, hi-tensile steel, with over-sized radiused blades |
| Headset |
Threaded |
| Wheels |
Alloy 26 x 1.50” 36H rims, heavy-duty ATB hubs with QR, 14G nickel-plated spokes |
| Tires |
CST MTB, 26 x 1.95” |
| Derailleurs |
Shimano TY300 rear and Shimano TZ30 front |
| Shift Levers |
Shimano Revoshift 35, 3×7-speed |
| Chain |
KMC Z51, 7-speed |
| Cassette |
7-speed freewheel, 13-28T |
| Crankset |
Forged alloy crank, 42/34/24T, 170mm |
| Bottom Bracket |
Bolt type axle |
| Pedals |
MTB platform, hi-impact resin |
| Brakes |
Alloy linear pull type with full alloy 4-finger levers |
| Handlebar |
Jamis XC riser, 25.4 x 20mm rise x 620mm |
| Stem |
Jamis Hi-Rise, Quill type – 60mm (12-14”), 80mm (15-18”), 100mm (19-21”) |
| Grips |
Kraton for Grip Shift |
| Seatpost |
Jamis alloy micro-adjust, 28.6 x 350mm (12-15”) 400mm (17-21”) |
| Saddle |
Jamis ATB Sport, SL cover, protective front and rear guards |
| Weight |
31.75 lbs |
Geometry
| Size | 13" | 15" | 17" | 19" | 21" | 12" S/O | 14" S/O | 18" S/O |
|---|---|---|---|---|---|---|---|---|
| Top Tube Effective | 20.90 / 531 | 21.42 / 544 | 21.89 / 556 | 22.52 / 572 | 23.34 / 593 | 20.51 / 521 | 20.75 / 527 | 22.01 / 559 |
| Head Tube Angle | 70.5° | 70.5° | 71° | 71° | 71.5° | 70.5° | 70° | 70.5° |
| Seat Tube Angle | 74° | 74° | 73.5° | 73.5° | 73° | 74° | 73° | 72.5° |
| Chainstay | 16.73 / 425 | 16.73 / 425 | 16.73 / 425 | 16.73 / 425 | 16.73 / 425 | 16.93 / 430 | 16.93 / 430 | 16.93 / 430 |
| Wheelbase | 40.27 / 1023 | 40.83 / 1037 | 40.90 / 1039 | 41.57 / 1056 | 42.05 / 1068 | 39.88 / 1013 | 39.96 / 1015 | 40.83 / 1037 |
| Fork Rake | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 | 1.77 / 45 |
| Bottom Bracket Height | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 | 11.89 / 302 |
| Headtube | 4.13 / 105 | 4.72 / 120 | 4.92 / 125 | 5.12 / 130 | 6.49 / 165 | 4.13 / 105 | 4.92 / 125 | 5.51 / 140 |
| Standover | 27.05 / 687 | 28.27 / 718 | 29.29 / 744 | 30.51 / 775 | 32.12 / 816 | 24.76 / 629 | 25.27 / 642 | 26.18 / 665 |
| Wheel Size | 26" | 26" | 26" | 26" | 26" | 26" | 26" | 26" |
